#include <Slave.h>
Public Member Functions | |
| SlaveWrap (uint32_t min, uint32_t max) | |
| Constructs a memory-slave wrapper instance. | |
| uint32_t | doMinAccess () |
| Returns minimum transaction access size. | |
| uint32_t | defDoMinAccess () |
Calls the base-class doMinAccess() implementation. | |
| uint32_t | doMaxAccess () |
| Returns maximum transaction access size. | |
| uint32_t | defDoMaxAccess () |
Calls the base-class doMaxAccess() implementation. | |
| uint64_t | doAddress () |
| Returns base address contribution for this slave. | |
| uint64_t | defDoAddress () |
Calls the base-class doAddress() implementation. | |
| void | doTransaction (std::shared_ptr< rogue::interfaces::memory::Transaction > transaction) |
| Services a transaction request from an attached master. | |
| void | defDoTransaction (std::shared_ptr< rogue::interfaces::memory::Transaction > transaction) |
Calls the base-class doTransaction() implementation. | |
 Public Member Functions inherited from rogue::interfaces::memory::Slave | |
| Slave (uint32_t min, uint32_t max) | |
| Constructs a memory slave. | |
| virtual | ~Slave () |
| Destroys the memory slave instance. | |
| virtual void | stop () |
| Stops the memory slave interface. | |
| void | addTransaction (std::shared_ptr< rogue::interfaces::memory::Transaction > transaction) |
| Adds a transaction to the internal tracking map. | |
| std::shared_ptr< rogue::interfaces::memory::Transaction > | getTransaction (uint32_t index) |
| Gets a transaction from the internal tracking map. | |
| uint32_t | min () |
| Returns configured minimum transaction size. | |
| uint32_t | max () |
| Returns configured maximum transaction size. | |
| uint32_t | id () |
| Returns unique slave ID. | |
| void | setName (std::string name) |
| Sets slave name. | |
| std::string | name () |
| Returns slave name. | |
| virtual uint32_t | doSlaveId () |
Services SlaveId request from a master. | |
| virtual std::string | doSlaveName () |
Services SlaveName request from a master. | |
| void | lshiftPy (boost::python::object p) |
Supports << operator usage from Python. | |
| std::shared_ptr< rogue::interfaces::memory::Master > & | operator<< (std::shared_ptr< rogue::interfaces::memory::Master > &other) |
| Connects this slave to a master via chaining operator. | |
| Public Member Functions inherited from rogue::EnableSharedFromThis< rogue::interfaces::memory::Slave > | |
| std::shared_ptr< rogue::interfaces::memory::Slave > | shared_from_this () |
Returns a shared_ptr<T> for this instance. | |
| Public Member Functions inherited from rogue::EnableSharedFromThisBase | |
| virtual | ~EnableSharedFromThisBase () |
| Virtual destructor for polymorphic base usage. | |
Additional Inherited Members | |
| Static Public Member Functions inherited from rogue::interfaces::memory::Slave | |
| static std::shared_ptr< rogue::interfaces::memory::Slave > | create (uint32_t min, uint32_t max) |
| Creates a memory slave. | |
| static void | setup_python () |
| Registers this type with Python bindings. | |
Detailed Description
Constructor & Destructor Documentation
◆ SlaveWrap()
| rogue::interfaces::memory::SlaveWrap::SlaveWrap | ( | uint32_t | min, |
| uint32_t | max | ||
| ) |
Member Function Documentation
◆ defDoAddress()
| uint64_t rogue::interfaces::memory::SlaveWrap::defDoAddress | ( | ) |
Calls the base-class doAddress() implementation.
Return offset.
Used as the fallback when no Python override is present.
- Returns
- Address offset in bytes.
◆ defDoMaxAccess()
| uint32_t rogue::interfaces::memory::SlaveWrap::defDoMaxAccess | ( | ) |
Calls the base-class doMaxAccess() implementation.
Return max access size to requesting master.
Used as the fallback when no Python override is present.
- Returns
- Maximum transaction access size in bytes.
◆ defDoMinAccess()
| uint32_t rogue::interfaces::memory::SlaveWrap::defDoMinAccess | ( | ) |
Calls the base-class doMinAccess() implementation.
Return min access size to requesting master.
Used as the fallback when no Python override is present.
- Returns
- Minimum transaction access size in bytes.
◆ defDoTransaction()
| void rogue::interfaces::memory::SlaveWrap::defDoTransaction | ( | std::shared_ptr< rogue::interfaces::memory::Transaction > | transaction | ) |
Calls the base-class doTransaction() implementation.
Post a transaction. Master will call this method with the access attributes.
Used as the fallback when no Python override is present.
- Parameters
-
transaction Transaction object to process.
◆ doAddress()
|
virtual |
Returns base address contribution for this slave.
Return offset.
Invokes the Python override when provided.
- Returns
- Address offset in bytes.
Reimplemented from rogue::interfaces::memory::Slave.
◆ doMaxAccess()
|
virtual |
Returns maximum transaction access size.
Return max access size to requesting master.
Invokes the Python override when provided.
- Returns
- Maximum transaction access size in bytes.
Reimplemented from rogue::interfaces::memory::Slave.
◆ doMinAccess()
|
virtual |
Returns minimum transaction access size.
Return min access size to requesting master.
Invokes the Python override when provided.
- Returns
- Minimum transaction access size in bytes.
Reimplemented from rogue::interfaces::memory::Slave.
◆ doTransaction()
|
virtual |
Services a transaction request from an attached master.
Post a transaction. Master will call this method with the access attributes.
Invokes the Python override when provided.
- Parameters
-
transaction Transaction object to process.
Reimplemented from rogue::interfaces::memory::Slave.
The documentation for this class was generated from the following files:
